Toro 2000 Series 60" Deck 24.5 HP 708cc Engine 77285
Toro 2000 Series 60" Deck 24.5 HP 708cc Engine
The Toro 2000 series is the go to mower for small commercial contractors or larger acreage home-owners. The Toro Z Master 2000 60" (77285) packs a 4-year / 1000 Hour Product Warranty. This machine is guaranteed to make quick work of big lawn jobs.
PRE ORDER NOW FOR MARCH 2023 DELIVERY
Toro 2000 Series 60" Features
-
60" TURBO FORCE® Cutting Deck - Built to last. Enjoy years of reliable performance with an upgraded 7-gauge steel, 5.5" deep deck.
-
Low-Back Suspension Seat - Stay comfortable on the job with the premium low-back shock absorbing suspension seat.
-
24" Toro Voodoo Trac™ Drive Tires - Get the ultimate in aggressive tread and styling with 24" Toro Voodoo Trac™ Drive Tires.
Toro 2000 Series 60" Specifications
| Anti Scalp Wheels | Standard |
|---|---|
| Blade Tip Speed | 18,500 ft/min / 5,638 m/min |
| CARB Compliant | CARB Compliant |
| Caster Tires | 13" x 6.5" x 6" (33 cm x 16.5 cm x 15.2 cm) Pneumatic |
| Clutch | Electromagnetic |
| Cutting Width | 60 in / 152 cm |
| Deck Design | 5.5” (14 cm) deck depth, 7-Gauge High-Strength Steel TURBO FORCE® w/ bull-nose bumper |
| Discharge Chute | Rubber |
| Drive Tires | Voodoo Trac 24" x 9.5" – 12" (61 x 24.1 – 30.5 cm) |
| Engine | 24.5 hp* Toro V-Twin 708cc with Heavy Duty Air Cleaner |
| Engine Brand | Toro |
| Engine Displacement (cc) | 708cc |
| Engine Horsepower | 24.5 hp |
| Foot Operated Height of Cut | Standard |
| Forward Ground/Transport Speed | Up to 10.0 mph / 16.0 kph |
| Fuel Capacity | 7 gal. / 26.5 L / 28 Qt. |
| Fuel Type | Gasoline |
| Height of Cut | 1.5 - 5.0 in / 3.8 - 12.7 cm in 0.25 in (0.64 cm) increments |
| Hitch Bracket | Standard |
| Hour Meter | Standard Hour Meter |
| Ignition | Electric |
| Lighting | LED Headlights |
| Mower Type | Zero Turn Mower |
| Notes: | Hitch: Integrated Receiver Hitch - 2x2 80 lbs (36.3 kg) max tongue, 250 lbs (113.4 kg) max tow |
| Product Use | Commercial |
| Roll-Over Protection (ROPS) | Folding; Standard |
| Spindle Housing | 8 in / 20.3 cm Diameter Aluminum (Non Greasable) Ball Bearing, 1 in / 2.5 cm Shaft |
| Start Type | Electric |
| Steering Controls | 1.4" (3.6 cm) Diameter Grips; Adjustable, Dampened |
| Tool Mounting Capability | Side Console / Rear Guard Ready |
| Transmission | Hydro-Gear ZT-3400 |
Disclaimer
Specifications subject to change without notice and without incurring obligation. Products depicted are for demonstration purposes only. Actual products offered for sale may vary in design, required attachments and safety features.
*The gross horsepower of these engines was laboratory rated by the engine manufacturer in accordance with SAE J1940 or SAE J2723. As configured to meet safety, emission and operating requirements, the actual engine horsepower on these mowers will be significantly lower.
*The gross horsepower of these engines was laboratory rated by the engine manufacturer in accordance with SAE J1940 or SAE J2723. As configured to meet safety, emission and operating requirements, the actual engine horsepower on these mowers will be significantly lower.
Parts & Manuals
Select your model year from the options below to view parts & manuals.
| 77285 Serial # |
|---|
| 400000000-999999999 |
Accessories
Hypr-Oil™ 500 (quart) (Part # 114-4713)
High Performance Hydro Oil
Hypr-Oil™ 500 (gallon) (Part # 114-4714)
High Performance Hydro Oil
Hypr-Oil™ 500 Hydraulic Oil (Part # 114-4715)
Maximize commercial mower performance with Hypr-Oil™ 500. Tested and approved by Toro Engineering.
Riding Mower Jack Kit (Part # 127-6666)
Genuine Toro jack mount kit. Mounts to the front of the mower and allows the owner to raise the mower to gain access to the underside of the deck to check blades or wash the deck. To best protect your investment and maintain optimal performance of your turf equipment, count on Toro genuine parts. When it comes to reliability, Toro delivers replacement parts designed to the exact engineering specifications of our equipment. For peace of mind, insist on Toro genuine parts.
Toro Titan Turf Tweel (Part # 139-3649)
A MICHELIN® X® TWEEL® airless radial tire is a single unit that replaces the current tire and wheel assembly. There is no need for complex mounting equipment and once they are bolted on, there is no air pressure to maintain The unique energy transfer within the poly-resin spokes helps reduce the “bounce” associated with pneumatic tires, while providing outstanding handling characteristics. They are designed to perform like pneumatic tires, without the inconvenience and downtime caused by flat tires. When it comes to reliability, Toro delivers replacement parts designed to the exact engineering specifications of our equipment. For peace of mind, insist on Toro genuine parts.
52 Inch Recycler Kit (Part # 139-6653)
The 52 in. Recycler Kit, when installed on compatible 42 in. deck Toro zero turn riding mowers, gives it the capability to mulch grass by cutting it multiple times turning it into fine clipping pieces. These are returned under the mower back into the soil to serve as natural fertilizer. When it comes to reliability, Toro delivers replacement parts designed to the exact engineering specifications of our equipment. For peace of mind, insist on Toro genuine parts.
Handle Extension Kit (Part # 145-3615)
Genuine OEM Part
